Name: Conductive Thermal Heating Pad for GPU , 8.5W/mK Thermal Conductivity Silicone Thermal Pad
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF7160RUS Series
Price: 4.10 USD
Availability: InStock

Startseite Produkte thermische Auflage des Kühlkörpers

Conductive Thermal Heating Pad for GPU , 8.5W/mK Thermal Conductivity Silicone Thermal Pad

Produktdetails:

Place of Origin:	China
Markenname:	Ziitek
Zertifizierung:	UL & RoHS
Model Number:	TIF7160RUS Series

Zahlung und Versand AGB:

Minimum Order Quantity:	1000pcs
Preis:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Kontakt

Ausführliche Produkt-Beschreibung

Features:	Available in different thinkness options	Products name:	High Quality Thermal Pad Conductive Silicone Thermal Heating Pad Gpu
Application:	GPU,Laptop,Electric and Battery cooling	Thermal Conductivity:	8.5W/mK
Keywords:	Silicone Thermal Heating Pad	Flam rating:	94 V-0
Hardness:	20 Shore 00	Thinkness range:	4.0mmT
Color:	Gray
Hervorheben:	Conductive Thermal Heating Pad , GPU Silicone Thermal Pad , Silicone Thermal Heating Pad

High Quality Thermal Pad Conductive Silicone Thermal Heating Pad Gpu

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

TIF^®7160RUS Series use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

Features:
> Excellent thermal conductivity 8.5W/mK

> Moldability for complex parts
> Soft and compressible for low stress applications
> Moldability for complex parts
> Outstanding thermal performance
> High tack surface reduces contact resistance

Applications:
> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> Micro heat pipe thermal solutions
> Automotive engine control units
> Telecommunication hardware
> Notebook
> Power supply
> Heat pipe thermal solutions
> Memory Modules

Typical Properties of TIF^®7160RUS Series
Color	Gray	Visual
Construction & Compostion	Ceramic filled silicone	*****
Specific Gravity	3.2 g/cc	ASTM D792
Thickness	4.0mm	ASTM D374
Hardness	20 (Shore 00)	ASTM 2240
Continuos Use Temp	-40 to 200℃	******
Dielectric Breakdown Voltage	≥3500 VAC	ASTM D149
Dielectric Constant	5.1~6.1 MHz	ASTM D150
Volume Resistivity(Ohm-cm)	＞1.0*1.0¹²	ASTM D257
Fire rating	94 V0	UL (E331100)
Thermal conductivity	8.5W/m-K	ASTM D5470

Product Specification
Product Thicknesses: 0.040inch (1.0mm)~0.200inch (5.00mm)

Product Sizes:8" x 16"(200mm x400mm)

Individual die cut shapesand and custom thickness can be supplied. Please contact us for different thickness.For more information about thermalconductivity materials, please contact us.

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated.

Independent R&D team

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us.

4. We will reply you as soon as possible with Email or online.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
